Sinoboom self-propelled articulated telescopic work platform AB10ERJN brand new-brand new-
IG: 3841

Technical specifications:
Max. working height: approx. 11.62 m
Max. platform height: approx. 9.62 m
Max. lateral reach: approx. 6.3 m
Max. payload: 230 kg / 2 persons
Transport width: approx. 1.20 m
Power supply: 48V battery incl., automatic charger
Proportional travel speed: 0.7 – 5 km/h
Net weight: approx. 6,760 kg

Features:
-Lifting platform for indoor and outdoor use
-Proportional control
-Simultaneous driving and slewing of the upper carriage possible
-No overhang
-Battery charge indicator on both control panels
-Automatic basket levelling
-Inclinometer 3°
-Rotating work platform
-Movable platform arm, vertical 132.2°
-Movable platform arm, horizontal 180° (3D platform arm)
-Towing and lifting eyes
-Non-marking tyres

-See brochure for technical specifications. Expected to be available in 0 days.
